1"Air Impact Wrenches
Model :
AB-562GL 1"
The air tool designed in swing hammer mechanism which the torque can be operated to the maxium, 2508(ft-lb) 3400N.M weight is 29.9lbs(14kgs) The long 2" & 2.5" anvil to chooice, also has same torque but the weight is 34.2lbs (15.5kgs). The wrench is straight type designed easy to work in any deep angle area. The pneumatic tool has thread in different continent, North America NPT; PF.BSP for European or Asia would be PF thread. Easy to use in the heavy tyres (big truck/pick up truck).
| Information |
Bolt Capacity |
Clutch Type |
Free Speed |
Suitable Torque | Max Torque |
Overall Length |
Net Weight |
Air Consumption |
Air Inlet | Air Hose |
Air Pressure |
||||
| Model | Size | mm | Mechanism | r.p.m. | ft-lb | N.M. | ft-lb | N.M. | mm | lbs | kg | m3/min | PT(in.) | mm | kg/c㎡ |
| AB-562GL | 1" | 56 | Swing Hammer | 3000 | 1328-1948 | 1800-2640 | 2508 | 3400 | 614 | 34.2 | 15.5 | 0.6 | 1/2" | 12.7 | 6.3 |
